![EP2](http://temposonics.eu/images/mtssensorslibraries/sensorsimagelibrary/temposonics-position-sensor-ep2-jpg.jpg?sfvrsn=eacf7a59_11)
Developed for use with floating magnet along the entire housing
- Flexible mounting
- Robust aluminum profile
- Multi-position measurement up to 8 magnets
- Outputs: Analog, CANbus, IO-Link, SSI, Start/Stop
Output | Stroke Length | Resolution | Status ⓘ |
---|---|---|---|
Analog | 50…2540 mm (2…100 in.) |
Infinite |
Active |
Start/Stop | 50…3000 mm (2…118 in.) |
Controller dependent |
Active |
SSI | 50…2540 mm (2…100 in.) |
20 µm |
Active |
CANopen | 50…2540 mm (2…100 in.) |
10 µm |
Active |
IO-Link | 50…2540 mm (2…100 in.) |
5 µm |
Active |
